Tips of the floor drain installation for the swimming pool

This is a big topic but also important for daily working of the floor drain installation workers. The swimming pool is not the same of the hotel and home application. Floor drain installation has always been a main focus of swimming enthusiasts. A good floor drain installation in the swimming pool can effectively prevent the odor of the sewer from returning from the floor drain, can also play a very good anti-insect, anti-blocking, anti-flooding role, then in the installation of floor drain should pay attention to what matters?
Floor drain is a sanitary equipment to remove indoor ground water, its main task is to remove indoor ground water and prevent harmful gases from the drainage system into the room. It has three basic requirements:
First, have a certain drainage capacity.
Second, with a certain depth of water seal, that is, more than 5 cm.
Third, have a certain ability to clean up pollution.
However, the floor drain and there are two special:
First, it is excluded from the surface water, water quality is sometimes worse than any other equipment, solid, fiber, easy to deposit in the water bend;
Second the time interval between two adjacent drainage is longer than that of other instruments, so that the deposit is solid and can not be cleared by the next drainage. Therefore, the floor drain drainage generally do not have a water trap, and in the floor drain product itself to make water seal structure, easy to remove sediment. It is suggested that the users should be informed of the necessity of water seal rotation to ensure the freshness and disinfection of water seal. Avoid mosquito breeding.
Here I list some skills for floor drain installation:
First, the location of floor drain installation-installation of floor drain, to install as low as possible, should first determine the location of floor drain, floor tile to floor drain spread slope, good in the floor drain location paved brick, floor drain installed to the middle of a brick, the diagonal is open, so it’s like this, and it will drain well, and if the floor drain is right between the two bricks, that’s it, you are doing right.
Second, according to the caliber of the drain in advance with the floor drain-buy floor drain to know the caliber of the floor drain drain drain pipe, now is generally 50 PVC pipe, cast iron to larger. The diameter of the ground drain should match the diameter of the PVC pipe material. In general, the reserved holes of the drainage are relatively large when the house is handed over. It is necessary to repair them during decoration. The drain should be made according to the size of the ground drain. Do not repair the drain first, then go and buy floor drain.
At last, the connection between the floor drain and the sewer-the general floor drain connection is able to insert into the sewer pipe, see the four anti-leakage into the sewer look like. Because this floor drain needs to be filled with a water seal core, it can not be made too thin. If another ring is added inside, then the water seal core must be made a little thinner, so it is made to look like this. There is only a ring stuck on the sewer pipe, does not affect installation.
Floor drain installation should pay attention to the following matters:
A.The purpose of the floor drain installation is to drain, so the location of the floor drain installation to be slightly lower than the ground, convenient drainage. Before the floor drain is installed, if the drain pipe is too close to the ground, the drain pipe should be cut short, so as to ensure that the installed floor drain panel is slightly lower than the ground.
B.Floor drain installation to take into account the convenience of future maintenance, so when filling cement mortar, can not directly use floor drain, but with Kraft paper or other strong material rolled to match the cylinder with the sewer pipe, and the sewer pipe butt, and raise it above the ground, then fill it with cement mortar.
C.Floor drain installation must be removed before the core drain, so that sundries can avoid falling into the core drain, causing damage.
D.Floor drain installation, in order to prevent tools and other items fall into the drain caused by blockage, prior to the use of cloth or other soft items will drain plug, with the installation of floor drain core when taken out.
E.In order to ensure that the overall decoration effect is not destroyed, the location of the floor drain installation can not be too much lower than the ground, so if the drainage pipe is too far from the ground, the application of cement mortar filling, in this way, the aim of increasing the drain pipe can be achieved, and the floor drain can be installed to ensure the perfect decorative effect.
About floor drain SHENZHEN RISINGSUN will be stopped here, thanks for your watching, hope can give you some good idea when you are facing the installation issues, if you have any questions welcome to communicate with us freely, wish you a happy life. Bye for now.
